01GTC SeriesElectric Chain Hoist
Electric Chain Hoist – Suspended Type
- Capacity
- 125–5,000 kg
- FEM / ISO
- 2M / M5
Electric Chain Hoist
Electric Chain Twin Hook Hoist – 500 Kg to 10 Ton
A stable, balanced twin-hook design for the simultaneous lifting of large, long loads.
- Capacity
- 500 kg–10 t
- FEM / ISO
- 1Bm / M3
Description
- This special chain hoist comes with classification FEM (1Bm) / ISO (M3).
- A stable and balanced design, with motor and brakes of insulation class F.
- Preferably used when the transport of large, long loads demands stable and safe simultaneous lifting.
- Ambient temperature: −20 °C to +40 °C.
Technical specifications
Datasheet on request| Capacity | 500 kg – 10 t |
|---|---|
| Classification FEM (ISO) | 1Bm (M3) |
| Motor & brake insulation | Class F |
| Ambient temperature | −20 °C to +40 °C |
| Hook distance | On request |
Need full dimensions, a datasheet or a configuration for your application? Request a quote and our sales team will reply with the details.
Series
Electric Chain Hoists GTC Series
Our chain hoist line is distinguished by its compact design, superior quality and high standard of safety. Every hoist is confirmed by the CE mark and is load tested before being delivered to the customer.
The high-strength alloy components and parts go through multiple special heat-treatment processes, giving them high strength and good abrasion performance. The top and bottom hooks of our hoists are made of high-strength alloy.
Related products
More Electric Chain Hoists
- 01GTC Series
02GTC SeriesElectric Chain Hoist
Electric Chain Hoist with Hand-Push Trolley
- Capacity
- 125–5,000 kg
- FEM / ISO
- 2M / M5
03GTC SeriesElectric Chain Hoist
Electric Chain Hoist with Electric Trolley
- Capacity
- 125–5,000 kg
- FEM / ISO
- 2M / M5
